6AV2124-0UC24-1AX0 Siemens

The 6AV2124-0UC24-1AX0 is a Siemens SIMATIC HMI TP1900 Comfort Pro Panel, designed for installation on a supporting foot system (expandable, bottom flange). With a 19-inch widescreen TFT display and support for 16 million colors, it offers superior visualization and usability for advanced industrial automation applications.

Key specifications:

• Touchscreen Operation: Smooth and intuitive interface for precise control
• Display: Large 19-inch widescreen TFT with vibrant color depth and excellent clarity
• Mounting: Designed for supporting foot installations with expandable configuration and bottom flange compatibility
• Connectivity: Equipped with PROFINET and MPI/PROFIBUS DP interfaces for versatile network integration
• Configuration Memory: 24 MB, supporting complex and sophisticated applications
• Operating System: Powered by Windows Embedded Compact 2013 (WEC 2013) for modern and reliable performance
• Software Compatibility: Configurable with WinCC Comfort V14 SP1 or later, with HSP (Hardware Support Package)

The TP1900 Comfort Pro Panel is ideal for demanding industrial environments, combining advanced functionality, high-resolution visualization, and a durable supporting foot-mounted design for flexible deployment.
